ac led
ML7-3 Modular LED Street Light (AC Powered)
Model: ML7-3
The ML7-3 modular LED street light runs on AC mains (no solar), with SMD 5050 120pcs and a tool-free modular design for fast field service. 10-15m pole.
Warranty
3-5 yr
MOQ
10 pcs
Lead time
15-25d
CE
Certified
RoHS
Certified
ISO 9001
Certified
Technical data
Specs, plain.
Every value verified on the production line. Need a parameter not listed? Ask us.
| Size | L675*W300*H80MM |
|---|---|
| LED | SMD 5050 120pcs |
| Install Height | 10-15m |
| Input Voltage | AC 85-305V |
| Material | Aluminum + PC |
| Warranty | 3 years |
About this product
What it does.
ML7-3 modular LED street light is the AC-powered workhorse of our roadway lineup. The modular LED engine (SMD 5050 120pcs) runs on AC 85-305V input, with surge protection up to 6kV, PF≥0.95, and IP65 housing.
Each module is independently replaceable — if one module fails in the field, you swap a single module instead of the whole fixture, cutting service costs by 60-70%. Tool-free latch design means a single technician with a 4mm hex key can complete a module swap in under 5 minutes.
Typical applications: city streets, municipal roads, parking lots, industrial parks, port terminals, and airports. Available in 10-15m pole heights with optional photocell, dimming, and smart-city control nodes. CE, RoHS, ISO 9001 certified.
Common questions
Asked & answered.
The things buyers ask us most. Don't see yours? Send a question — we reply within 24 hours.
Generic for category
What is the warranty?
3 years on the full fixture, 5 years on the LED module, 10 years on the solar panel. We replace any defective unit at our cost.
What is the MOQ?
10 pieces for standard models. 50 pieces for fully custom builds. Sample orders of 1-3 pieces ship from stock at a small premium.
What is the lead time?
7-15 days for samples. 15-25 days for bulk orders under 500 pieces. 25-35 days for 500-2000 pieces. We confirm exact lead time with every quote.
How do I install it?
Every shipment includes a printed installation guide. Most fixtures mount to a standard 60mm pole tenon with 4 M8 bolts. No special tools needed.
