BY-3A Split Solar Street Light
The BY-3A split solar street light separates the LED engine and battery from the solar panel — higher wattage, longer autonomy, easier maintenance. 3.2V 150AH / 3.2V 300AH battery, 8-15m pole.
3 items · Click thumbnails to view
split100W*4
TSP-4 Cylindrical Solar Panel
Model: TSP-4
Cylindrical solar panel for split solar street light systems. 100W*4 output, L1000*W171*H171MM, 145mm mount, IP65 sealed.
Warranty
3-5 yr
MOQ
10 pcs
Lead time
15-25d
CE
Certified
RoHS
Certified
ISO 9001
Certified
Technical data
Specs, plain.
Every value verified on the production line. Need a parameter not listed? Ask us.
| Size | L1000*W171*H171MM |
|---|---|
| Solar Panel | 15V/100W*4 |
| Install Diameter | 145mm |
| Cable Length | 3m |
| Material | Aluminum + PC |
| Warranty | 3 years |
About this product
What it does.
The TSP-4 cylindrical solar panel is the high-performance PV source for our split solar street light systems. 100W*4 output from a sealed L1000*W171*H171MM tube assembly, terminated with a standard 145mm mounting interface and 3m pre-wired cable for fast installation.
Cylindrical panels are used where the panel needs to be mounted separately from the LED head — typically on top of an existing pole or on a dedicated solar mount, away from the light engine. This separation keeps the panel free of shading from trees, signage, or the LED body itself, and gives installers more flexibility on tilt and orientation.
Each tube is built with high-efficiency monocrystalline cells, anti-reflective tempered glass, and a weather-sealed anodized aluminum frame. IP65 rated at the junction box. The 145mm mount diameter is compatible with most standard pole-top tenon brackets; custom diameters available on request.
Common questions
Asked & answered.
The things buyers ask us most. Don't see yours? Send a question — we reply within 24 hours.
Generic for category
What is the warranty?
3 years on the full fixture, 5 years on the LED module, 10 years on the solar panel. We replace any defective unit at our cost.
What is the MOQ?
10 pieces for standard models. 50 pieces for fully custom builds. Sample orders of 1-3 pieces ship from stock at a small premium.
What is the lead time?
7-15 days for samples. 15-25 days for bulk orders under 500 pieces. 25-35 days for 500-2000 pieces. We confirm exact lead time with every quote.
How do I install it?
Every shipment includes a printed installation guide. Most fixtures mount to a standard 60mm pole tenon with 4 M8 bolts. No special tools needed.
Need a custom configuration?
Different wattage, color temperature, or pole height? We adjust to spec. Most custom orders ship in 25-30 days.
