solar yard
SG-Y505 Solar Yard Light
Model: SG-Y505
Large-format solar yard light with 150-180 lm/W LED output. IP65, 3.2V/30AH battery, ideal for courtyards, plazas, parking areas.
Warranty
3-5 yr
MOQ
10 pcs
Lead time
15-25d
CE
Certified
RoHS
Certified
ISO 9001
Certified
Technical data
Specs, plain.
Every value verified on the production line. Need a parameter not listed? Ask us.
| Size | Φ505*H340MM |
|---|---|
| LED | SMD 3535 150LM/W |
| Battery | 3.2V/30AH |
| Solar Panel | 5V/30W |
| IP Rating | IP65 |
| Color Temperature | 3000K/4000K/6000K |
| Material | Aluminum + PC |
| Warranty | 3 years |
About this product
What it does.
The SG-Y505 solar yard light is a large-format landscape fixture designed for courtyards, plazas, parking areas, and residential community spaces. SMD 3535 150LM/W LED module delivers 150-180 lm/W typical output, illuminating a wide area from a single 3-5m pole.
Φ505*H340MM die-cast aluminum housing, IP65 rated. The 3.2V/30AH battery and 5V/30W provide 10-12 hours of full-brightness output per night with 2-3 backup days. Color temperature selectable (3000K/4000K/6000K).
Common applications: residential community courtyards, hotel entrances, plaza squares, parking lot perimeter lighting, school grounds, and park areas. The compact round form factor is a popular alternative to traditional bollard-style fixtures.
Common questions
Asked & answered.
The things buyers ask us most. Don't see yours? Send a question — we reply within 24 hours.
Generic for category
What is the warranty?
3 years on the full fixture, 5 years on the LED module, 10 years on the solar panel. We replace any defective unit at our cost.
What is the MOQ?
10 pieces for standard models. 50 pieces for fully custom builds. Sample orders of 1-3 pieces ship from stock at a small premium.
What is the lead time?
7-15 days for samples. 15-25 days for bulk orders under 500 pieces. 25-35 days for 500-2000 pieces. We confirm exact lead time with every quote.
How do I install it?
Every shipment includes a printed installation guide. Most fixtures mount to a standard 60mm pole tenon with 4 M8 bolts. No special tools needed.
